VSP Vacuum Transducer ● Pirani ● 1000 to 1e-4 mbar ● analog

The Analogline VSP is based on a new, patented measurement principle. The well proven Thyracont impulse Pirani sensor provides a larger measuring range with higher resolution. It uses an optimized temperature compensation. Accuracy and stability have been further improved. Overview VSP vacuum transducer with Pirani sensor: Long-living: Durable, elastic Pirani helix filament Wide measuring range: Patented impulse Pirani with extended measuring range; very high resolution also in the rough vacuum range Well protected: Integrated metal facing for protection against contamination like oil vapours or solvent vapours Perfect: Highest reliability and excellent reproducibility UHV suitable: Due to metal sealed stainless steel measuring cell (He leakage rate <5e-10 mbar l / s) Overpressure resistant: Overpressure stability up to 16 bar Controllers on request: Suitable for 1 and 2 channel controller VD6 / VD12 Overview Analogline vacuum transducers: Stable: Stable, reproducible measurement values due to its microprocessor controller and individual temperature compensation Long-living: With its robust metal housings and plugs with protection class IP54 (4-20 mA versions) or IP40 (0-10 V versions) the transducers are ideal for rugged industry environments Easy adjustment: Precise, digital adjustment to zero pressure and atmosphere at the push of a button. The vacuum transducer automatically recognizes the adjustment point Optimal cost-performance-ratio: The functionalities of the Analogline are reduced to minimum to achieve an optimal cost-performance-ratio Small dimensions: Compact construction, ideal for industrial applications with reduced space. Easy integration: The linear and logarithmic output signal of the transducer (optionally 4-20 mA or 0-10 V) can easily read out with a system control (PLC) Do you have questions regarding our VSP vacuum transducers with Pirani sensor? We will be pleased to assist. → Go to all vacuum transducers of the Analogline | → Go to accessories for all Analogline vacuum transducers
