3.2 inch OLED Touch Screen Portrait Strip Type 262×928

Part Number IF032BM26-92C Brand IFANTEK Diagonal Size 3.2″ Panel Type AM-OLED, OLED Resolution 262(RGB)×928 Orientation Portrait type Display Area 22.008 × 77.952 (H×V) mm Outline Size 23.808 × 81.052 × 0.63 (H×V×D) Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Luminance 500 cd/m² (Typ.) Color Gamut 16.7M 100% NTSC Contrast Ratio 10000 : 1 (Typ.) (TM) Interface MIPI 1-lane I2C, 30 pins Response 2 ms (Typ.) Driver IC OLED RM690C0, CTP ZT2628 Operating Temperature -20 ~ 70 °C Application Instruments, Smart Home Product Overview The 3.2 inch portrait strip 262×928 OLED touch screen is a color active matrix AMOLED module using Low Temperature Poly-silicon TFT’s (Thin Film Transistors) as active switching devices. This module has a 3.19 inch diagonally measured active area with 262×928 resolutions (262 horizontal by 928 vertical pixel arrays). Each pixel isdivided into RED, GREEN, BLUE dots and this module can display 16.7M colors. The OLED Revolution OLED (Organic Light Emitting Diodes) technology has revolutionized the display industry, offering several advantages over traditional LCD displays. These include: Superior Image Quality: OLED displays have a much higher contrast ratio compared to LCDs, providing deeper blacks and more vibrant colors. Thinner and Lighter: OLED displays do not require a backlight, making them thinner and lighter than their LCD counterparts. Faster Refresh Rates: OLED displays have faster refresh rates, reducing motion blur in fast-moving scenes. 3.2 inch OLED Touch Screen Features This 3.2 inch OLED 262×928 portrait strip touch screen comes with a host of impressive features: High Resolution: The screen offers a resolution of 262×928 pixels, providing clear, sharp images with vibrant colors. MIPI Interface: The screen uses a MIPI (Mobile Industry Processor Interface) for high-speed data transfer. Touch Panel: The screen comes with an integrated touch panel, providing a seamless user interface. Driver IC: The screen uses the RM690C0 driver IC, known for its reliability and performance.
