21 inch Native Bar Type LCD 1920×132

21 inch Native Stretched Bar Type LCD Module 1920×132 Video: https://ifan-display.com/wp-content/uploads/2023/04/21-inch-Stretched-Bar-LCD-Module-1920x132-web-video.mp4 Specifications: Part Number DV210FBM-N00 Brand BOE Diagonal Size 20.9″ (Native bar) Panel Type a-Si TFT-LCD , LCM Resolution 1920(RGB)×132 92PPI Orientation Landscape type Display Area 529.416×36.3974 (H×V) mm Outline Size 542.4×54.7×8.0 (H×V×D) mm Display Mode HADS,Normally Black,Transmissive Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Luminance 300 cd/m² (Typ.) Color Gamut 16.7M 73% NTSC Contrast Ratio 1200:1 (Typ.) (TM) Interface LVDS (2 ch, 8-bit) , 40 pins Response 8 (Typ.)(G to G) ms Operating Temperature 0 ~ 50 °C Application Digital Signage, Stretched Bar LCD Product Overview The 21 inch Native Stretched Bar Type LCD 1920×132 offers a multitude of features and benefits that make it an ideal choice for various industries and applications. It is high resolution display, full viewing angle, IPS LCD technology, and diverse applications, combined with its environmentally friendly production process, make the 21 inch Native Bar Type LCD a superior display solution. 21 inch Native Bar LCD Features High-Resolution Display DV210FBM-N00 is manufactured by BOE, a well known display technology company. The 21 inch bar display features a stretched bar display measuring 20.9 inches and boasts a 1920×132 pixels. This high resolution display ensures that images and text appear crisp and sharp, provide an enhanced visual experience. IPS Technology Full Viewing Angle The 21 inch Native Stretched Bar Type LCD is equipped with an In-Plane Switching (IPS) LCD panel, which offers a full viewing angle of 89/89/89/89 (Typ.)(CR≥10). This means that the display can be viewed from any angle without color distortion or loss of image quality. The IPS LCD technology also ensures accurate color reproduction and improved contrast ratios, making it ideal for various applications. LVDS Interface and 40-pin Connectivity The 21 inch Bar Type LCD has an LVDS (Low Voltage Differential Signaling) interface with 2 channels and 8-bit data transmission. This enables high speed data transfer and reduced power consumption. Additionally, the display is equipped with a 40-pin connector, allowing seamless integration with other devices and systems.
